[Qidi X-CF Pro, speziell für den Druck von Kohlefaser und Nylon entwickelt] - [QIDI Online Shop DE]

€1.099,00 €749,00

Tax included. Shipping calculated at checkout.

VAT included.

Product Features

Print Speed up to 600mm/s
Large size 325*325*315mm
Max 65℃ active chamber heating
All-around performance right out of the box

Ship from

EU warehouse

Quantity

Ship from EU Local Warehouses

In Stock - Ship in1-3 businessdays,Free shipping

— The best industrial grade FDM high speed all-round 3d printer —

QIDI Tech
X-MAX 3

-Faster Speed 600mm/s
-Bigger than bigger
-325*325*315 mm
-High-Flow 35mm³/s
-Acceleration: 20000mm/s²

MAX 3 configures the above technologies for truly fast printing

KLIPPER

64-bit
Processor

Cortex-A53
Main frequency 1.5GHz, 8G-EMMC and 1G DDR3

New All-metal Frame

Ultra-stable, reinforced with metal crossbeams at the bottom, resistant to deformation.

High-grade hardness steel linear hollow optical axis

Improved surface straightness, and a 60% lower error deflection.
Highly durable and No need for frequent maintenance.
Typically last a lifetime without the need for replacement.

CoreXY Structure

Reduce the motion Inertia and improve the motion speed.
TMC2209 silent drive less noise.

New cooling system

Reducing the risk of clogs and ensuring smooth extrusion.

9.5:1 gear ratio

Steadier, powerful, faster extrusion.

Two Sets of Hot End

Copper alloy nozzle for better thermal conductivity, smooth printing and to be more durable.
Hardened steel nozzle for abrasive materials, and long term usage.
Both 350℃ Max Print Temp.

Temperature Controlled Chamber
And Drying Box

Active Heating Device
Maximum Temp 65℃
High efficiency printing PET-CF,PAHT-CF etc
Chamber circulation fan with activated carbon air filter.

No Layer Separation

The higher the temperature in the heated chamber, the larger the material range that can be printed. The heated chamber ensures that the part is built uniformly without the generation of internal stresses.

We Only Produce High Performance Materials

-Professional Printing Industrial Grade Materials-

Automatic Leveling

Klipper Adaptive Meshing and Purging, fast ensure flawless first layer for every 3D print.

Flexible HF Plate

Excellent adhesion,
No warping trouble,
Easy to remove the prints.

Excellent User Experience

The highly acclaimed QIDI slicer software has both normal mode and expert mode, which is also easy for beginners to get started!
We also provide the Fluidd Console.

For more information, please visit our official wiki(wiki.qidi3d.com).

Specifications

Machine Name
	X-Max3	X-Plus3	X-Smart3

Technology	FDM
Build Volume (W×D×H)	325325315mm	280280270mm	175180170mm
Dimensions (W×D×H)	553553601mm	511527529mm	370362397mm
Net weight (kg)	30.2	24.3	10.5
Printing Speed	≤600mm/s		≤500mm/s
Extruder Flow:	35mm³/s @PLA Matte(Model:150*150mm single wall; Material: PLA Rapido Matte;Temperature: 240℃)		30mm³/s
Extruder Temp	≤350°C		≤300°C
Hotend (Included)	Copper alloy nozzle hotend For Common materials		Brass Nozzle hotend
	Hardened steel nozzle hotend For Abrasive materials
Auxiliary Part Cooling Fan	✔	✔	✖
Chamber Temperature Control	65°C Independent Chamber Heating	65°C Independent Chamber Heating	✖
Chamber Circulation Fan With Activated carbon air filter	✔	✔	Chamber Circulation Fan
Screen	5.0 inch		4.3 inch
	800*480 touch screen		480*272 touch screen
Seal print	Dryer Box + Desiccant		Optional
Connection Options	150M 2.4G Wi-Fi USB Flash Drive/Ethernet Cable		150M 2.4G Wi-Fi USB Flash Drive
Rated Power	900W	800W	350W
Recommended Filament	PAHT-CF,PET-CF,PA12-CF		PLA
Compatible filament	PLA, ABS, ASA, PETG, TPU, PC, UltraPA, Nylon, etc.		ABS, ASA, PETG, TPU etc
Structure	CoreXY
Z Axis：	Double Z axis
X axis	High-grade hardness steel linear hollow optical axis		Hardened Wear-resistant Carbon Fiber Rod
Firmware:	Klipper
Printing Acceleration:	20000mm/s²
Printing Accuracy:	±0.1 mm
Filament diameter:	1.75mm
Bed Leveling:	Automatic Leveling
Extruder transmission ratio	9.5:1
Hot end:	Ceramic Heating Core
Extruder:	High-flow Direct Drive Extruder
Nozzle diameter:	0.4mm (0.2,0.6,0.8mm Optional)
Hot bed temperature:	≤120℃
Printing Plate:	Double-Sided Flexible Magnetic Plate
Filament Detection:	Yes
Resonance Compensation：	Yes
Pressure Advance：	Yes
Voltage:	100-240VAC, 50/60Hz
Main Processor:	Cortex-A53,64-bit Processor
	1.5Ghz,8G-EMMC,1G DDR3
Slicer:	QIDI Print and other third-party software, such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc.
Operating System:	Windows, MacOS, Linux
Assembled	Assembled and First Print within 10 minutes
	Learn more	Learn more	Learn more

Machine Name
X-Max3	X-Plus3	X-Smart3

Technology：FDM
Build Volume (W×D×H mm)
325325315	280280270	175180170
Dimensions (W×D×H mm)
553553601	511527529	370362397
Net weight (kg)
30.2	24.3	10.5
CoreXY
Z Axis：Double Z axis
X axis： High-grade hardness steel linear hollow optical axis		X axis： Hardened Wear-resistant Carbon Fiber Rod
Firmware：Klipper
Printing Speed
≤ 600mm/s		≤ 500mm/s
Extruder Flow：
35mm³/s @PLA Matte(Model:150*150mm single wall; Material: PLA Rapido Matte;Temperature: 240℃)		30mm³/s
Printing Acceleration：20000mm/s²
Printing Accuracy：± 0.1 mm
Extruder Temp
≤350℃		≤300℃
Filament diameter：1.75mm
Bed Leveling： Automatic Leveling
Extruder transmission ratio：9.5:1
Hot end： Ceramic Heating Core
Extruder：High-flow Direct Drive Extruder
Nozzle
Copper alloy nozzle (For Common Filaments) Hardened steel nozzle (For Abrasive Filaments)		Brass Nozzle
Nozzle diameter
0.4mm (0.2,0.6,0.8mm Optional)
Hot bed temperature： ≤120℃
Printing Plate：Double-Sided Flexible Magnetic Plate
Auxiliary Part Cooling Fan
✔	✔	✖
Chamber Temperature Control
65°C Independent Chamber Heating		✖
Chamber Circulation Fan With Activated carbon air filter
✔	✔	Chamber Circulation Fan
Screen
5.0 inch 800*480 touch screen		4.3 inch 480*272 touch screen
Seal print
Dryer Box + Desiccant		Optional
Connection Options
150M 2.4G Wi-Fi USB Flash Drive/ Ethernet Cable		150M 2.4G Wi-Fi USB Flash Drive
Filament Detection： Yes
Resonance Compensation: Yes
Pressure advance：Yes
Voltage：100-240VAC, 50/60Hz
Rated Power
900W	800W	350W
Main Processor：Cortex-A53,64-bit Processor 1.5Ghz,8G-EMMC,1G DDR3
Slicer
QIDI Slicer and other third-party software, such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc.
Operating System： Windows, MacOS, Linux
Recommended Filament
PAHT-CF,PET-CF,PA12-CF		PLA
Compatible filament
PLA, ABS, ASA, PETG, TPU, PC, UltraPA, Nylon, etc.		ABS, ASA, PETG, TPU etc
Assembled and First Print within 10 minutes
Learn more	Learn more	Learn more
